Selling point
- RJ45 port, adaptive 10/100/1000Mbps, full/half duplex mode
- IP40 protection, -40 ° C~ 80 ° C wide temperature working temperature, excellent EMC protection performance
- Small size, space saving, cost-effective choice
Characteristic
- This series of products complies with CE, RoHS 2.0
Specification parameter
| Parameter / Product model | YM-IES05 | YM-IES10 | |
| Performance specifications | Number of ports | 5 | 10 |
| Communication speed | Adaptive 10/100/1000Mbps | ||
| Protocol standard |
IEEE 802.3 IEEE 802.3u IEEE 802.3x Compatible with Profinet protocol |
||
| Input voltage | 24 VDC | ||
| Electrical protection | Support lightning surge impact protection (4KV), and anti-static interference | ||
| Power | ＜5 W | ＜10 W | |
| Testing and certification | CE/RoHS 2.0/EMC anti-interference | ||
| Operating conditions | Operating temperature | -40 ~ 80 ℃ | |
| Storage temperature | -40 ~ 80 ℃ | ||
| Relative humidity | 5% ~ 95% No condensation | ||
|
Mechanical features
|
Size | 63.7*22*112 mm | 78.5*41*112 mm |
| Protection class | IP40/Aluminum alloy shell | ||
| Mode of connection | Cold-free terminal in-line connection | ||
| Assembly method | 35mm DIN rail type | ||
| Heat dissipation mode | Natural cooling | ||
Matters need attention
- This series of products will be upgraded and improved from December 1, 2023, and the product length will be reduced from 78.7mm to 63.7mm. The function and performance of the product remain unchanged, please rest assured to use it.
